ESIE09-05 Field Setting
Test Operation 97
(5.2) Y-control
Cooling: T
e set
- T
e real
= A
If A > B for C minutes, thermo off is applied for C minutes.
Heating: T
c real
- T
c set
= A
If A > B for C minutes, thermo off is applied for C minutes.
After C minutes, the units starts to operate.
(5.3) Z-control
Standard Daikin thermostat on/off control.
(6) Target Refrigerant Temperature Setting
(6.1) X-control
 Cooling: Upper & lower limit of T
e
can be chosen
Mode n° setting Setting switch n° Setting position n° Setting
B (°C) C (min)
51 2 00 2 3
01 4 3
02 6 3
03 8 3
04 2 5
05 45
06 6 5
07 8 5
08 2 7
09 4 7
10 6 7
11 8 7
12 2 10
13 4 10
14 6 10
15 8 10
Mode n° setting Setting switch n° Setting position n° Setting
Lower limit T
e
(°C)
Upper limit T
e
(°C)
51 1 00 -7 20
01 -3 20
02 0 20
03 3 20
04 -7 15
05 -3 15
06 0 15
07 3 15
08 -7 10
09 -3 10
10 0 10
11 3 10
12 -7 8
13 -3 8
14 0 8
15 3 8
