Si20-701_B Troubleshooting by Remote Controller
470
Voltage Measuring Method
CHECK 7
Outdoor unit PCB
Pressure sensor
Micro-computer
A/D input
GND
+5V
Connector
Red
Red
Black
White
(4)
(3)
(2)
(1)
Measure DC voltage here.
