1-20
1.5.7 Information Interchange with Personal Computer
The electronic controller has an internal memory function to record the set point temperature, refrigeration
temperature, operation mode, occurrence alarm and the report of automatic PTI during transportation in
addition to the normal operation control.
Data download
Data records can be downloaded by connecting a PC to the communication port. To download the FULL
TRIP data which contains most large data, connect a USB memory to the connection port on the controller.
Software upload
The software in the controller can be updated by uploading software using a PC or USB memory.
The use of a PC also enables the container number, cargo description, destination and other information to
be sent to and memorized in the controller.
Description PC connection USB memory connection
Download
Trip report
FULL TRIP ✓
✓
All data are downloaded
in a lump.
LAST ONE TRIP ✓
TRIP BY DATE ✓
TRIP BY TRIP ✓
PTI report ✓
USDA report ✓
Monitoring report ✓✓
Upload
Software upload ✓✓
Container No. etc. upload ✓
Note 1. Download the file with authentication into a USB memory from the web site.
2. See ※14-1 and ※14-2 menu in paragraph 2.3 for the procedure of downloading and uploading by
connecting a USB memory.
3. When you see the downloading data from USB flash memory by PC, install the DCCS software
(ver. 9 series) in advance.
4. Refer to the "Operation manual for personal computer software" for the procedure for downloading
and uploading via a PC.
PC connected to the communication port
USB memory
USB memory connected to the controller
To Next Page
