1.1 Main Specifications
Item Main Specifications
Mode Switch
Chilled mode +30.0℃ 〜 -9.9℃ (+86.0F 〜 -14.1F)
Frozen mode -10.0℃ 〜 -30.0℃ (+14.0F 〜 -22.0F)
Condenser cooling system Air cooling dedicated type
Controller DECOSⅤ
Power source
Three phase 50Hz : 380/400/415V、60Hz : 440/460V
Voltage fluctuation rate should be within ±10%.
Inverter compressor Hermetically sealed scroll type (MAX. motor output : 8.1 kW)
Evaporator Cross-fin coil type
Air cooling condenser Cross-fin coil type
Evaporator fan Propeller fan
Evaporator fan motor
Squirrel-cage three phase induction motor (Motor output:
440W/60W), dual speed, 2P/4P
Condenser fan Propeller fan
Condenser fan motor
Squirrel-cage three phase induction motor (Motor output:
670W/120W), dual speed, 4P/6P
Defrosting system Hot-gas defrosting system
Refrigerant control Electronic expansion valve
Capacity control By inverter compressor and hot-gas defrost control
Refrigerant (charged quantity)
R134a (For refrigerant charging amount, refer to the name
plate, unit performance)
Refrigerant oil (charged quantity) IDEMITSU, Daphne hermetic oil FVC68D (1.9 L)
Weight For detail, refer to the name plate, unit performance
●The resistance of solenoid coil
Component name Coil Resistance
Compressor motor 0.52Ω (20℃ ), 0.63Ω(75℃ )
Condenser fan motor High speed: 30.6Ω±5% (20℃ ) / Low speed: 21.6Ω±5% (20℃ )
Evaporator fan motor High speed: 17.2Ω±5% (20℃ ) / Low speed: 11.4Ω±5% (20℃ )
Solenoid valve LSV, ESV, HSV, RSV 15.2 Ω±10% (20℃ )
Modulation valve EEV, EMV, DMV 46±3Ω/phase （20℃）
