Removal Procedure SiBE81-909
70 Humidifying Air Purifier
9. Removal of the plasma
ionizer unit
★
To prevent the humidifying
air purifier from falling down,
support the humidifying air
purifier while removing the
plasma-ionizer unit.
★
There is a hook on the each
side.
1
Hold the grips of the
plasma ionizer unit.
Pull the unit toward
yourself and lift up to
remove.
2
When assembling,
catch the 2 lower hooks
first.
Step Procedure Points
(R9790)
Hooks
Grips
Plasma ionizer unit
(R9764)
Contact
switch
Hook
(R9791)
To Next Page
