SiBE81-909
Removal Proced
ure
Humidifyi
ng Air Purifier
75
8.3
Removal of Streamer Unit
Warning
Be sure t
o wait 10 minutes or more after t
urning off al
l power supplies befor
e
disassembling work.
Step
Procedure
P
oints
1
Pull
out the st
reamer
unit.
Caut
ion
Do not disass
emble the
str
eamer electr
ic disc
harge unit
.
Replace i
t as a unit.
(R9803)
Streamer
electric
discharge
unit
Unit 2 mark
75
77
