Removal Procedure SiBE81-909
76 Humidifying Air Purifier
8.4 Removal of lonizing Wire
Warning Be sure to wait 10 minutes or more after turning off all power supplies before
disassembling work.
Step Procedure Points
1
Undo the 2 hooks and
lift the opposing pole
plate to detach.
★
The opposing pole plate has
the same shape in 4
directions.
2
Pinch and detach the
ionizing wires with
pincers.
Caution
Be careful not to get your hands
cut by the ionizing wires.
★
Once removed, the ionizing
wires cannot be reused.
★
When cleaning the ionizing
wires, do not remove them.
(See the Operation Manual.)
(R9807)
Hook
Hook
Hook
Hook
(R9808)
Opposing pole plate
(R9809)
