Daikin MCK75JVM-K Service Manual

Removal Procedure SiBE81-909
90 Humidifying Air Purifier
4
Wiring of the power
cord.
Step Procedure Points
(R9840)
(R9841)
Humidifying rotor ASSY
Water pan ASSY
Put the wire harness
through the groove
of the casing.
Put the wire harness
through the groove
of the casing.
Wire the harness of the
proximity sensor (float
switch) under the
power cord.

Daikin MCK75JVM-K Specifications

General

Brand	Daikin
Model	MCK75JVM-K
Category	Air Cleaner
Language	English
