Service Information
attribute name and the applicable settings for each. The factory
default values are shown in bold font.
Configuration
string position
Description Values (default in bold)
Main Control Board (MCB) Data Archiving
All MCB control parameters and the real time clock settings
are backed
up by the MCB battery when power is removed
from the MCB. In the event of a battery failure, the MCB
includes a data archiving function. Once a day, just after
midnight, all the MCB control parameter settings are archived
to a file stored in the MCB FLASH memory. If the MCB is
powered up with a low or defective battery (or with the battery
removed), the most recently archived data is restored to the
controller.
Note – When this archived data restoration process occurs, it
increases the controller start up and initialization time
period by approximately 75 seconds.
Table 22: Software configuration string
1Unit Type
0
RA zone control
1RA DAT control
2 100 OA zone control
3100 OA DAT control
2 Cooling Type
0None
1 Compressorized clg
2 Chilled water (2-wire FB)
A Chilled water (3-wire FB)
3
Compressoriz
ed cooling
configuration
0 2 comp/2 stage
1 2 comp/3 stage
2 2 comp/4 stage
3 2 comp/6 stage
4 3 comp/4 stage
5 4 comp/4 stage
6 6 comp/6 stage
7 4 comp/8 stage
8 Generic condenser
4
Generic
condenser
stages
1 – 8 Stages
(Default = 8
)
5 Low ambient
0No
1Yes
6
*
Condenser
fan type
0 No evap cond control
1 2 cond fans/cir– ABB VFD
2 2 cond fans/cir– Graham VFD
3 2 cond fans/cir– Reliance VFD
4 2 cond fans/cir– no VFD
5 3 cond fans/cir– ABB VFD
6 3 cond fans/cir– Graham VFD
7 3 cond fans/cir– Reliance VFD
8 3 cond fans/cir– no VFD
7 Damper type
0None
1 Single position 30% (2-wire FB)
2 Single position 100% (2-wire FB)
3 Economizer (2-wire FB)
A Single position 30% (3-wire FB)
B Single position 100% (3-wire FB)
C Economizer (3-wire FB)
8 DesignFlo
0 No DesignFlo
1 018–030 (800) (non-precision PS)
2 036–040 (802) (non-precision PS)
3 045–075 (047) (non-precision PS)
4 080–135 (077) (non-precision PS)
A 018–030 (800) (precision PS)
B 036–040 (802) (precision PS)
C 045–075 (047) (precision PS)
D 080–135 (077) (precision PS)
9 Heating type 0None
1F BP ctrl
2Multi staged
3Modulated gas, 3–1 (2-wire FB)
4Modulated gas, 20–1 (2-wire FB)
5Steam or hot water (2-wire FB)
6Single stage gas
7Single stage electric
AModulated gas, 3–1 (3-wire FB)
BModulated gas, 20–1 (3-wire FB)
CSteam or hot water (3-wire FB)
10
Max heating
stages
1 – 8 stages
(default = 1)
11,12, and 13 Max heat rise Three digits
(default = 100)
14
Discharge fan
type
0 Constant volume
1 Variable inlet vanes
2 Variable freq drive
15
Return fan
type
0 Constant volume
1 Variable inlet vanes
2 Variable freq drive
3 No Return fan
4 Propeller exhaust
16
Return/
exhaust fan
capacity
control
method
0None
1 Tracking
2 Bldg press
3 Position
17
Second
pressure
sensor type
0None
1Duct
2Bldg
18
Entering fan
temp sensor
0No
1Yes
19
Energy
recovery
0None
1 Constant speed wheel
2 Variable speed wheel
20 Final filter
0No
1Yes
21
Heating
configuration
0 Draw through preheat
1 Draw through reheat
2 Blow through
22
Cooling
configuration
0Draw through
1Blow through
Table 22: Software configuration string (continued)
Configuration
string position
Description Values (default in bold)
