Caution indicates a potentially hazardous situations, which can result in
minor injury or equipment damage if not avoided.
Warning indicates a potentially hazardous situations, which can result in
property damage, personal injury, or death if not avoided.
Danger indicates a hazardous situation, which will result in death or serious
injury if not avoided.
NOTICE
Notice indicates practices not related to physical injury.
Installation and maintenance must be performed by qualied personnel
familiar with applicable codes and regulations, and experienced with this
type of equipment.
PreciseLine units are not designed to be weather resistant; DO NOT install
outdoors.
Check grounding nut tightness before connecting power to the external
junction box.
Store unit on a level surface. If air handling units are to be
stored for any period of time, it is important to rotate the motor
shaft (quarterly, as a minimum) to prevent permanent distortion
of drive components.
Store units indoors in a clean, dry environment on a level
surface. Moisture, debris, and minerals can cause permanent
damage to the cabinet and components. Do not allow
coverings to trap moisture on the galvanized surface.
When in a warehouse (i.e. not in transit), horizontal units Size
006-020 can be stored 3 units high. Vertical units Size 006-
and 5 units high with one. Do not stack units Size 030 and
larger.
A registered professional engineer must design and approve the air
conditioner and air handler application to make sure smoke and fume
control meet local re codes and NFPA requirements for the specic
building application. Due to the wide variation in building design and
ambient operating conditions into which our products can be applied,
we do not represent or warrant that our products will be t and sufcient
for smoke and fume control and management purposes. The owner and
building designer must consult a registered professional engineer to satisfy
themselves in this regard.
The system design and installation must follow accepted
industry practice, such as described in the ASHRAE
Handbook, the National Electric Code, and other applicable
standards. The installation of this equipment must be in
accordance with regulations of authorities having jurisdiction
and all applicable codes. It is the responsibility of the installer
to determine and follow the applicable codes.
1. Carefully check items against the bills of lading to verify
all crates and cartons were received. Carefully inspect
all units for damage when received. Report visible and
claim for damage within 5 days.
2. PreciseLine air handler units are thoroughly inspected
before leaving the factory. Install units carefully to
prevent damage.
3. All fans are dynamically balanced before leaving the
factory. Carefully inspect fans for rough handling that can
cause misalignment or a damaged shaft.
4. Horizontal units Size 006-020 may be stacked 3 units
high for transit.
5. Vertical units Size 006-020 may be stacked for transit
6. Never stack units Sizes 030-100
