Daikin PreciseLine Series User Manual

IM 1267-7 • PRECISELINE AIR HANDLER 4 www.DaikinApplied.com


Category Code Description
Model Type BC Daikin Applied Air Handler
Unit Arrangement
H Horizontal
V Vertical
A
AVD / Compact Vertical (Sizes 006-
020)
Fan Arrangement
D Draw Thru Forward-Curved Fan
E Draw Thru Plenum Fan, End Discharge
U Draw Thru Plenum Fan, Up Discharge
Model Size
006 Nominal 600 CFM
008 Nominal 800 CFM
010 Nominal 1,000 CFM
012 Nominal 1,200 CFM
016 Nominal 1,600 CFM
018 Nominal 1,800 CFM
020 Nominal 2,000 CFM
030 Nominal 3,000 CFM
040 Nominal 4,000 CFM
050 Nominal 5,000 CFM
060 Nominal 6,000 CFM
080 Nominal 8,000 CFM
100 Nominal 10,000 CFM
Design Series 1 1st Vintage
Voltage
A 115/60/1
E 208/60/1
G 460/60/1
K 230/60/1
P 277/60/1
D 208/60/3
L 230/60/3
T 460/60/3
W 575/60/3
Primary Coil
Connection Location
L Left Hand (Air back of the head)
R Right Hand (Air back of the head)
C Center
Category Code Description
Primary Coil Type
W Water / Glycol
D DX / 410A
V VRV
Secondary (Heat-
ing) Coil Location
P Preheat
R Reheat
Y None
Secondary (Heat-
ing) Coil Conneciton
Location
L Left Hand (Air back of the head)
R Right Hand (Air back of the head)
Y None
C Center
Secondary (Heat-
ing) Coil Type
W Hot Water / Glycol
Y None
S Steam
Corrosion Package
A
(Coil Casing) Stainless / (Fin Coating)
None / (Drip Pan Corrosion Pkg.)
Stainless
Y
(Coil Casing) Galvanized / (Fin Coat-
ing) None / (Drip Pan Corrosion Pkg.)
Galvanized
Mix Box Openings
T Top + Rear
B Bottom + Rear
Y None
Mix Box Actuator
Type
T ON/OFF
A 0-10V M
M Manual
Y None
Discharge Plenum
Opening
B Bottom
T Top
E End
Y None - No Discharge Plenum
R Right Hand (Air back of the heat)
L Left Hand (Air back of the head)
F Field Cut-Out (Has a Plenum)
 Not all code options shown.
