www.DaikinApplied.com 75 IM 1267-7 • PRECISELINE AIR HANDLER


Figure 89: Left-Hand, Single and Dual Fan (Sizes 006-020))
G
J
H
A
K
F
B
C
E
D
W
S
BB
CC
X
L
.75 Drain
.563 Mntg Holes (4)
M
AIR FLOW
M
S
W
AA
BB
X
T
V
AA
AIR FLOW
Note: Left hand unit shown, right hand unit same as left but opposite.
Cabinet Sizes:
006, 008, 010, 012
Top View
Cabinet
Length
Cabinet
Length
Cabinet
Height
Cabinet Width
Cabinet Width
V
T
L
Q
Q
R
R
Z
Y
1.00 Base
P
N
Cabinet Sizes:
016, 018, and 020
Top View
.563 Mntg Holes (4)
Primary Return
Secondary Return
(Optional)
Primary Supply
Secondary Supply
(Optional)
BB
Overall Cabinet Dimensions
006 = 43L × 24W × 18H
008 = 43L × 29W × 18H
010 & 012 = 46L × 37W × 18H
016 = 46L × 45.5W × 18H
018 & 020 = 46L × 54W × 18H
