Figure 99: Coil Section Dimensions (Sizes 060-100)
Table 65: General Unit Dimensions (Sizes 060-100)
    V   Y
SIZE 60 28.00 54.00 54.00 4.19 12.39 4.38 62.75 3.50
SIZE 80 28.00 54.00 62.00 5.45 12.39 4.38 62.75 3.50
SIZE 100 28.00 61.00 66.00 4.79 12.39 4.38 69.75 3.50
