IM 1267-7 • PRECISELINE AIR HANDLER 90 www.DaikinApplied.com
Figure 98: Vertical Discharge Plenum (Sizes 030-050)
Table 64: Discharge Plenum Dimension Letter Reference
H J M N
14.00 17.50 25.00 2.00 8.06 2.75 12.00 6.50 12.00 0.25 18.00 25.00 58.00
18.00 17.50 25.00 2.00 12.00 2.75 12.00 6.00 16.00 0.25 18.00 28.00 60.00
20.00 17.50 25.00 2.00 14.00 2.75 12.00 6.75 18.00 0.25 18.00 31.50 62.00
31.00 17.50 25.00 5.47 20.00 1.75 14.00 6.75 29.00 0.25 18.00 38.00 63.50
33.00 17.50 25.00 2.47 20.00 1.75 14.00 6.00 31.00 0.25 18.00 43.00 64.00
H J M N
26.00 30.00 31.00 2.00 20.00 5.00 20.00 10.00 24.00 0.50 31.00 44.00 56.00
30.00 30.00 31.00 2.00 24.00 3.00 24.00 10.00 28.00 0.50 31.00 48.00 60.00
30.00 30.00 31.00 2.00 24.00 3.00 24.00 10.00 28.00 0.50 31.00 48.00 68.00
Discharge Plenum
Cabinet shown for
reference. Use for both
AVD and Vertical
cabinets
Top View – Discharge Plenum
Front View
Side View
Cabinet Length
B
JH
N
Field Duct Flange
Cabinet Width
L
F
C
(Main cabinet removed for clarity)
M
G
A
B
