1. Cut the foam seal (adhesive type) to the proper length
and attach it to the window stool. Fig.8
2. Attach the window slider kit to the window stool. Adjust
the length of the window slider kit according to the width
of window, shorten the adjustable window kit if the width
of window is less than 27 inches.
Open the window sash and place the window slider kit on
the window stool. Fig.9
3. Cut the foam seal (adhesive type) to the proper length
and attach it on the top of the window. Shown as in
Fig.10.
4. Close the window sash securely against the window.
5. Cut the foam seal to an appropriate length and seal
the open gap between the top window sash and outer
window sash. Shown as in Fig.11.
Foam seal A
(adhesive type)
Window kit
Window stool
26.5” ~ 48”
INSTALLATION INSTRUCTIONS
Installation in a double-hung sash window
Window stool
Window kit
Foam seal
Fig. 8
Fig. 9
Fig. 10
Fig. 11
