Scoreboard Options
16
Time Outs Left (TOL) Digits
Reference Drawings:
T.O.L. Option Installation .................................................................................... DWG-149030
Certain scoreboards have the option to add a time outs left (TOL) digit for both the
home and guest teams. These digits are installed by simply unscrewing the blank face
panel, connecting and securing the digit, and manually applying the “T.O.L.” caption.
Refer to DWG-149030 in Appendix B for more information.
Changeable Caption Kits
Reference Drawings:
Changeable Team Name Caption Installation ............................................ DWG-1132576
Team name and statistics caption kits contain hardware for one caption only and consist
of an upper caption retainer, a lower caption retainer, a changeable caption panel
and screws. The standard HOME and GUEST captions are applied directly to the face of
the scoreboard. Team name captions are on changeable panels that t into retainers
mounted above and below the standard captions. If these retainers are not already
present, attach the retainers included with the caption kit. Caption kits are also available
for certain statistics display models to switch between basketball, volleyball, wrestling,
and hockey modes.
Refer to DWG-1132576 in Appendix B for changeable caption installation instructions.
Goal Lights
To install optional hockey goal lights, refer to the Indoor Hockey Goal Lights Manual (ED-
13358).
Protective Devices
Daktronics indoor displays have been designed so that indoor sports balls impact will
not damage the LEDs or display cabinet, reducing the need for protective devices.
However, Daktronics also makes optional protective devices, including screens and
netting, to help prevent damage to the display due to normal ball impacts. Refer to the
Protective Screen Installation Instructions (ED-5423) for more information about installing
protective devices.
Note: Some customers may choose to install devices to protect the display from
projectiles. Protective devices not provided by Daktronics must be approved by
Daktronics prior to installation. Failure to follow this approval procedure will void
the warranty.
