Version 06 teledynedalsa.com/ipd 18
Specifications
This following table lists the specifications of the BOA vision system:
General Specifications
Specification Definition
Memory Storage 256 MB Storage; 256MB Program
Image Sensor 1/3 inch CCD; 7.4 μm pixel size
Resolution 640x480
Type Mono or Color Progressive Scan
Exposure 22 us to 1000 ms
Acquisition Async
Reset, full-frame integration, 60f/s (application dependent)
Lens C Mount
I/O Trigger 1 opto-isolated hardware trigger input
Software trigger via Ethernet or internal timer
Inputs 1 General purpose opto-isolated.
Expandable via Ethernet I/O module
Outputs 2 General purpose opto-isolated
Expandable via Ethernet I/O module
Strobe 1 dedicated strobe output for LED light source
Status Network + 2 application assigned LEDs
Network Ethernet 10/100 BaseT
Serial RS232 1 Port –
flying leads on lamp connector
Power 12-30V Via Ethernet or IO connectors (not PoE
compliant)
Device 150 mA
maximum @ 24V (3.6 Watts)
Lamp 1A maximum (BOA powering light source directly)
Mechanical Material Machined Aluminum with anodize/paint finish
Mounting 8 x M4 plus optional mounting block
Size 44mm x 44mm x 56mm (without lens cover)
Environment Temp -10°C (14°F) to 50°C (122°F) Operating (-60°C to 80°C) Storage
Protection IP67 with cables attached
Shock 70 G
Certification FCC Class A and EU CE
