Version 06 teledynedalsa.com/ipd 7
BOA vision systems are shipped with the components listed below.
Take a few
moments to verify that everything has arrived in good condition.
If your product has
been visibly damaged during shipment or is missing parts, please
contact your
Teledyne DALSA representative immediately.
BOA Vision System Components
Component Description
BOA Vision System
BVS-0640M-INS OR
BVS-0640C-INS OR
BVS-1024M-INS OR
BVS-1280M-INS
BOA Vision System. Fully integrated vision system with
640x480 mono or color sensor, processing engine, iNspect
embedded software, communications and light control.
BVS-INS-CD CD including PC emulation software and associated product
manuals.
Mounting Screw Kit M4 screws for mounting the sensor (Qty 4)
Component Description
Cables
A-BVS-E8S-X
A-BVS-IO8S-X
A-BVS-L5S-X
M12-RJ45 Ethernet cordset
(X; 5=5m, 10=10m)
M12 single-ended IO cordset
(X ;5=5m, 10=10m)
M12 single-ended lamp cordset
(X; 2=2m, 5=5m)
BVS-PL-100 Panel Link breakout module. Provides Ethernet power and
convenient panel access to BOA I/O
A-MB-BVS-0 Right Angle mounting block with 8 M4 screws
Lens Various Lens options available from DALSA
A-BVS-LCG-X Lens cover for BOA Vision System. Required for IP67
compliance. (x=35, 40 or 45 mm internal lens length)
A-BVS-LSS-F
A-BVS-M12-P
Set screws for Fujinon
Lens
M12 plug for IP67 compliance
Lights Various Lighting options available from DALSA
Optional components (sold separately):
Standard components (ship with every BOA Vision System):
