26 Piranha2 User’s Manual
3.6 Setting Baud Rate
To set the speed of the camera serial communication port, use the command:
Syntax:
sbr i
Syntax Elements:
i
Baud rate. Available baud rates are: 9600 (Default), 19200, 57600,
and 115200.
Notes:
• Power-on rate is always 9600 baud.
• The rc (reset camera) command will not reset the camera to the
power-on baud rate.
Example:
sbr 57600
3.7 Setting the Data Mode
To select the camera output mode, use the command:
Syntax:
sdm i
Syntax Elements:
i
See Table 8: Mode Selection Values below for allowable parameter
values.
Notes: To obtain the current data mode, use the command gcp.
Example:
sdm 0
In the table below, ports A-F refer to ports in the Camera Link specification.
Table 8: Mode Selection Values
Mode Description
0 8-bit, using A/B/C/D ports for single processor configuration
1 10-bit, using A/B/C and D/E/F for single processor configuration
2 8-bit using ports A/B and D/E for dual processor configuration
3 10-bit, using A/B/C and D/E/F for dual processor configuration
To obtain the current data mode, use the command gcp.
03-32-00493-11 DALSA
