73 Piranha2 User’s Manual
GCP Screen Desctiption
section 3.9 Setting Line Rate
and Exposure Mode for details.
Exposure Time: 197.950 uSec
Current exposure time setting.
Value is set with the set
command. See section 3.9
Setting Line Rate and Exposure
Mode for details.
End-Of-Line Sequence: on
States whether an end of line
sequence is turned on or off.
Set using the eol command.
See section 3.17 Generating Test
Patterns for details.
Upper Threshold: 240
Upper threshold value set with
the sut command.
Lower Threshold: 15
Lower threshold value set with
the slt command.
Region of Interest: 0001-4096
Region of interest size set with
the roi command. See section
3.10 Setting a Region of Interest
for details.
C7 Commands
The following table lists all of the commands available to the camera user. The first
column of the table lists command codes returned as first code from
gps.
Code Command Short
Form
Parameters Description
0 calibrate_analog_gain
cag t i
Calibrates the analog gain. The
first parameter is the tap
selection 1 to 4, 0 for all taps.
The second parameter is a line
average in a range from 64 to
251DN for 8-bit mode and 256
to 1007DN for 10-bit. This
command requires a constant
light input and only works in
uncalibrated mode.
1 calibrate_analog_offset
cao t i
Calibrates the analog offset.
The first parameter is the tap
selection 1 to 4, 0 for all taps.
The second parameter is a line
average in a range from 1 to
100DN for 8-bit mode and 4 to
Parameters:
i = integer
f = float
t = tap selector
s = string
x1 = pixel start
number
x2= pixel end number
[]= optional
parameter
03-32-00493-11 DALSA
