39 Piranha2 User’s Manual
To read the FPN coefficient, use the command:
Syntax:
gfc i
Syntax Elements:
i
The pixel number to read.
Example:
gfc 10
3.16 Setting and Reading PRNU Coefficients
You can set or read an individual pixel’s PRNU coefficient.
To set the PRNU coefficient, use the command:
Syntax:
spc i i
Syntax Elements:
i
The pixel number from 1 to the pixel count.
i
Coefficient value in a range from 0 to 511 where:
512
1
i
PixelPRNU
+
=
Example:
spc 10 50
To read the PRNU coefficient, use the command:
Syntax:
gpc i
Syntax Elements:
i
The pixel number to read.
Example:
gpc 10
3.17 Generating Test Patterns
The camera can generate a test pattern to aid in system debugging. Use the command
svm 2 to activate the test pattern. The test pattern is a ramp from 0 to 255DN, then starts
at 0 again. Use the test pattern to verify the proper timing and connections between the
camera and the frame grabber.
End-of-line Sequence
To further aid debugging, the camera can generate an end-of-line sequence. The end-of-
line-sequence outputs "aa", "55", "aa", "line counter", "line average", "pixels above
threshold", "pixels below threshold", "derivative line sum". To activate the end-of-line
sequence, use the command
els 1. To disable the end-of-line sequence, use the
command
els 0.
03-32-00493-11 DALSA
