72 Piranha2 User’s Manual
GCP Screen Desctiption
after a power up.
Calibration status will
return to uncalibrated
after camera reboot or a
rpc or svm 0 command
had been issued.
SETTINGS COMMON TO CALIBRATED AND UNCALIBRATED MODES:
System Gain: 0 0 0 0
Digital gain value set with the
ssg command. See section 3.13
Setting Gains for details.
Background Subtract: 0 0 0 0
Background subtract value set
with the ssb command. See
section 3.12 Optimizing Offset
Performance for details.
Pretrigger: 0
Pretrigger value set with the sp
command. See section 3.20
Setting the Pre-trigger for
details.
Number of Line Samples: 64
Number of lines samples set
with the css command. See
section 3.11 Returning Video
Information for details.
Video Mode: 1
Current video mode value set
with the svm command. See
section 3.8 Setting the Video
Mode for details.
Data Mode: 0
Current data mode value set
with the sdm command. See
section 3.7 Setting the Data
Mode for details.
Exposure Mode: 2
Current exposure mode value
set with the sem command. See
section 3.9 Setting Line Rate
and Exposure Mode for details.
SYNC Frequency: 5000 (4998.51)
Hz
Current line rate. Value is set
with the ssf command. See
03-32-00493-11 DALSA
