71 Piranha2 User’s Manual
GCP Screen Desctiption
Analog Gain (dB): +0.0 +0.0 +0.0 +0.0
Analog gain value set with
the sg and cao commands.
Available only in
uncalibrated mode (svm
0).
See section 3.13 Setting
Gains for details.
Analog Offset: 308 324 304 292
Analog offset value set
with the sao and cag
command. The cag
command is available only
in uncalibrated mode (svm
1). See section 3.12
Optimizing Offset
Performance for details.
SETTINGS FOR CALIBRATED MODE:
Analog Gain (dB): +0.0 +0.0 +0.0 +0.0
Analog gain value set with
the sg or ccp command.
The ccp command is
available only in calibrated
mode (svm 1). See sections
3.13 Setting Gains and
White Light Calibration
(page 37) for details.
Analog Offset: 0 0 0 0
Analog offset value set
with the sao or ccf
command. The ccf
command is available only
in calibrated mode (svm
1). See section 3.12
Optimizing Offset
Performance and Dark
Calibration (page 36) for
details.
Digital Offset: 0 0 0 0
Digital offset value set with
the sdo command.
Available only in calibrated
mode (svm 0). See section
3.12 Optimizing Offset
Performance for details.
Calibration Status: FPN(uncalibrated)
PRNU(uncalibrated)
Calibration status will
change to calibrated
after a ccf or ccp
command has been issued
03-32-00493-11 DALSA
