57 Spyder2 User’s Manual
03-032-10091-06 Teledyne DALSA
Error Codes
Code Description Suggested Cause
outside the speci fi ed operating
range
20 N ot Used N ot Used
21
Analog offset calibration failure
Analog offset calibration failure (could not
tune the analog offset to obtain targeted
video l ev el )
22 Analog gain calibration failure
Analog gain calibration failure (could not
tune the analog gain to obtain targeted
video l ev el )
23 CRC check failure while
attempting to restore the camer a
settings
Camera setting will initialize to default
settings, si nce r estore of USER/ FA CTORY
settings failed (internal micro EE memory
failure)
24 Camer a settings not saved
rus
,
rfs
attempted but settings were not
sav ed
25 Pixel coefficients write failure Failure while writing pixel coefficients to
EEROM (I2C EEROM external to micro)
26
I2C communication fault while
accessi ng temperatur e sensor
Serial communication fault (I2C) while
accessi ng temperatur e sensor
27 Timeout waiting for DISC SYNC
to go LOW
Internal communication protocol error
28 Unable to cali br ate gain. Tap
number outsi de ROI.
Analog gain could not be calibrated because
tap number speci f i ed i n cag command is
outside regi on of i nter est.
29 Unable to cali br ate offset. Tap
number outsi de ROI.
Analog offset could not be calibrated
because tap number speci fi ed in cao
command i s outside region of interest.
Informal Message Codes
Code Description Suggested Cause
1
INFO: CRC check failure while
attempting to restore
calibration status
Pixel calibration status will be set to NOT
CA LIBRA TED (internal micro EEROM
failure)
2
INFO: CRC check failure while
attempting to restore pixel
coeff i cients
All pixel coefficients will be reset to zero
(external EEROM (I2C) failure)
4 IN FO: Flash memory ID error Reported from boot process, only if DSP
configuration fails (possible cause:
communication error with serial flash
memory )
8
INFO: DSP configuration file
missing or corrupt
Reported from boot process, only if DSP
configur ati on fails (possi ble cause)
16
INFO: Serial communication
failure while accessing
exter nal A DC chip
Reported from boot process if
communication verification fails with
exter nal A DC chip (camera vol tage
measur ement, SPI)
32 INFO: Calibration may be out-
of-speci f i cation (PRN U
coefficient clipped)
ccp
: several coef fi ci ents w er e clipped
during the ccp command process
