59 Spyder2 User’s Manual
03-032-10091-06 Teledyne DALSA
GCP Screen Description
Network Message Mode: disabled
Displ ays w hether netw ork
messages are enabl ed or
disabled. Set w i th the snm
command . See B1 N etw orking
Mode for details.
Firmware Design Rev.: xx-xx-xxxxx-xx
Firmware design revision
number.
DSP Design Rev.: xx.xx
DSP d esi gn r ev i si on number.
SETTINGS FOR UNCALIBRATED MODE:
Analog Gain (dB): +0.0
Analog gain value set with the
sg and cao commands.
Available only in uncalibrated
mode (svm 0).
See secti on 3.13 Setting Gains
for details.
Analog Offset: 695
A nalog off set value set w ith the
sao and cag command. The
cag
command is available only
in uncalibrated mode (svm 1).
See secti on
3.12 Optimizing
Offset Performance for details.
SETTINGS FOR CALIBRATED MODE:
Analog Gain (dB): +0.0
Analog gain value set with the
sg or ccp command. The ccp
command is available only in
calibr ated mod e (svm 1). See
sections 3.13 Setting Gains and
White Light Calibration (page
31) for details.
Analog Offset: 716
Analog offset val ue set w i th the
sao or ccf command. The ccf
command is available only in
calibr ated mod e (svm 1). See
section 3.12 Optimizing Offset
Performance and Dark
Calibration (page 31) for details.
Digital Offset: 0
Digital offset value set with the
sdo command. Available only
in calibrated mode (svm 0). See
section 3.12 Optimizing Offset
Performance for details.
Calibration Status: FPN(calibrated)
PRNU(calibrated)
Calibration status will change to
calibrated after a ccf or
ccp command has been i ssued
after a power up. Calibration
status will return to
uncalibrated after camera
reboot or a
rpc
or
svm 0
