Spyder3 GigE Vision User’s Manual
DALSA 03-032-20027-02
15
2
Mechanicals and Optics
2.1 Mechanical Interface
Figure 8: Spyder3 1k and 2k GigE Vision Camera Mechanical Dimensions
57.072.0
7.5
42.0
9.0
60.0
30.000 ±0.050
CCD IMAGING
CENTRE
36.000 ±0.050
CCD IMAGING CENTRE
M42X1 THREAD
DEPTH 4.0
50
60
6.56 ±0.25
TO CCD
IMAGING
SURFACE
UNITS: mm
10.8
23.1
11.9
16.3
11.5
30.0
20.0
14.0 32.0
6.0
M3
X
0.5 THRE
A
D
DEPTH 5.0 (4
X
)
