Exposure Mode, Readout Mode, Line Rate and
Exposure Time
Overview
You have a choice of operating in one of seven modes. The camera’s line rate
(synchronization) can be generated internally through the software command
AcquisitionLineRateAbs or set externally with an EXSYNC signal, depending on your
mode of operation.
To select how you want the camera’s line rate to be generated:
1. You must first set the camera mode using the DALSAExposureMode command.
2. Next, if using mode 2, 6, 7, or 8 use the commands AcquisitionLineRateAbs and/or
ExposureTimeAbs to set the line rate and exposure time.
1. Set the Exposure Mode
Sets the camera’s exposure mode allowing you to control your sync, exposure time, and
line rate generation.
DALSAExposureMode = {Mode = 2, Mode3 = 3, Mode4 = 4, Mode5 = 5,
Mode6 = 6, Mode7 = 7 }
• Factory setting is mode 7.
Related Commands: AcquisitionLineRateAbs, ExposureTimeAbs
Table 10: Spyder3 GigE Vision Exposure Modes
Programmable Line Rate Programmable Exposure Time
Mode SYNC PRIN Description
2
Internal Internal Yes Yes Internal frame rate and exposure time.
Exposure mode enabled (ECE).
3
External Internal No No Maximum exposure time. Exposure
control disabled (ECD).
4
External Internal No No Smart EXSYNC. ECE.
5
External External No No External sync, external pixel reset.
ECE.
6
External Internal No Yes Fixed integration time. ECE.
7
Internal Internal Yes No Internal line rate, maximum exposure
time. ECD.
8
Internal Internal No Yes Maximum line rate for exposure time.
ECE.
Note: When setting the camera to external signal modes, EXSYNC and/or PRIN must be supplied.
