Dalsa Spyder3 SG-11-01k80-00-R User Manual

Spyder3 GigE Vision User Manual
03-032-20027-02 DALSA
8
Feature / Specification 1k 2k 4k
Data Rate 40 or 80 MHz,
model
dependent
40 or 80 MHz, model
dependent
80 MHZ
Table 3: Camera Operating Specifications
Specifications Unit -10 dB 0 dB +10 dB
Min Typ Max Min Typ Max Min Typ Max
Broadband
responsivity
DN/(nJ/cm²)
1k and 2k Dual line 652.8 2064 6528
1k and 2k Single line 326.4 992 3264
4k Dual line 431 1363
4k Single line 216 682
Random noise rms DN
1k and 2k 3 6.5 9.2 20.5 30 65
4k 10 24
Dynamic range DN:DN
1k and 2k Dual line 500:1 1400:1 203:1 324:1 59:1 108:1
1k and 2k Single line 500:1 1400:1 203:1 324:1 59:1 108:1
4k Dual and Single 1225:1 387:1
FPN global DN p-p
Uncorrected 52.8 169.6 536
Corrected 32 32 64
PRNU ECD
Uncorrected local % 8.5 8.5 11.5
Uncorrected global % 10 10 10
Corrected local DN p-p 80 80 95
Corrected global DN p-p 80 80 95
4k Dual and Single
Corrected local DN p-p 32 32
Corrected global DN p-p 80 80
Uncorrected local % 9.5 9.5
Uncorrected global % 20 20
PRNU ECE
Uncorrected local % 8.5 12 37
Uncorrected global % 10 12 37
Corrected local DN p-p 80 237 752
Corrected global DN p-p 80 208 752
4k Dual and Single
Corrected local DN p-p 237 237
Corrected global DN p-p 237 237
Uncorrected local % 9.5 9.5
Uncorrected global % 20 20
SEE (calculated) nJ/cm²
1k and 2k Dual line 6.35 1.92 0.61
1k and 2k Single line 12.2 4.0 1.2
4k Dual line 9.2 2.9
4k Single line 18.0 5.7
NEE (calculated) pJ/cm²
