Spyder3 GigE Vision User’s Manual
DALSA 03-032-20027-02
37
27.78 1000 2K 2 Tap
54.1 1000 4k 2 Tap
twSync ns 100
twSYNC_INT ns 100
(3000*)
For exposure mode
4 this value needs to
be >3000ns other
wise >100ns
tPR ns 0
twPR_LOW ns 3000
twPR_HIGH ns 3000
tPR_INT ns 3000
Table 8: tReadout Values
tREADOUT
Sensor Size # Taps Readout Time
1024 1 25600ns
1024 2 12800ns
2048 1 51200ns
2048 2 25600ns
4096 2
Table 9: tOverhead Values
tOVERHEAD
Sensor Size # Taps Readout Time
1024 1 725ns
1024 2 450ns
2048 1 1400ns
2048 2 725ns
Overhead Delay
Overhead_Delay can range from 5 to 6μs and depends on the internal operations of your
computer.
