MECHANICAL INSTALLATION
41Dana IncorporatedIMM-0016EN - Installation and Maintenance Manual
Assemble the parts as shown bellow
1 - Bolt
2 - Washer
3 - Washer Ring
4 - Rubber Buffer
5 - Bolt
6 - Fixing Plate
7 - Bolt
1
2
3
4
4
5
6
7
