D&R Electronica Weesp BV (CINEMIX PARTLIST) DATE: 24-04-1998
Page 8
60883340 Cinemix patchpannel (basis) 10201193 | Print Cinemix 31A (backp2) | 1.0000 | st
------------------------------------------------------------------------------------------------- 10201194 | Print Cinemix 32C (backp3) | 1.0000 | st
Articlecode | Description | Quantity | Unit 10201189 | Print Cinemix 9B (backp1) | 1.0000 | st
------------------------------------------------------------------------------------------------- 10201197 | Print MUX-Amp1C (autom.) | 5.0000 | st
10650372 | Montagedraad 0.4 mm2 (zwart) | 1500.0000 | cm 10250333 | Transistor BC-327/25 (pnp) | 2.0000 | st
10700690 | Platstaf 25 x 10 x 10mm | 21.0000 | st 10350517 | Weerstand 0E 5% 1/4W | 35.0000 | st
10700636 | Platstaf 60 x 10 x 10mm | 73.0000 | st 10350765 | Weerstand 1M0 5% 1/4W | 6.0000 | st
10700611 | Popnagel 3.0 x 6.5 blank | 192.0000 | st 10350729 | Weerstand 1k0 5% 1/4W | 2.0000 | st
20850172 | Print bestukt Marilonpat-3 b/z | 32.0000 | st 10350703 | Weerstand 2E2 5% 1/4W | 23.0000 | st
20851111 | Print bestukt Merlin 11(patch) | 9.0000 | st 10350733 | Weerstand 2k2 5% 1/4W | 2.0000 | st
20851112 | Print bestukt Merlin 12(patch) | 1.0000 | st 10350842 | Weerstand 3k01 1% 1/4W | 4.0000 | st
20851113 | Print bestukt Merlin 13(patch) | 5.0000 | st 10350735 | Weerstand 3k3 5% 1/4W | 4.0000 | st
10700787 | Taptite M3x6 bolkoppozidr/zwrt | 84.0000 | st 10350736 | Weerstand 3k9 5% 1/4W | 4.0000 | st
10700790 | Taptite M3x6 verzkop/pozidr/zw | 212.0000 | st 10350737 | Weerstand 4k7 5% 1/4W | 2.0000 | st
10700681 | Tywrap kort 94 mm blank | 30.0000 | st 10350738 | Weerstand 5k6 5% 1/4W | 2.0000 | st
10700680 | Tywrap lang 150mm blank | 50.0000 | st 10350741 | Weerstand 10k 5% 1/4W | 4.0000 | st
60883346 Cinemix 4x row patchbay module 10350742 | Weerstand 12k 5% 1/4W | 2.0000 | st
------------------------------------------------------------------------------------------------- 10350744 | Weerstand 18k 5% 1/4W | 8.0000 | st
Articlecode | Description | Quantity | Unit 10350745 | Weerstand 22k 5% 1/4W | 2.0000 | st
------------------------------------------------------------------------------------------------- 10350860 | Weerstand 27k4 1% 1/4W | 2.0000 | st
10600041 | Connector sub-D25 female pcb | 8.0000 | st 10350713 | Weerstand 47E 5% 1/4W | 48.0000 | st
10600150 | Header haaks 1p opsteekkontkt | 4.0000 | st 10350754 | Weerstand 120K 5% 1/4W | 2.0000 | st
10600140 | Header haaks 34p (raster 2.54) | 4.0000 | st 10350756 | Weerstand 180K 5% 1/4W | 2.0000 | st
10600478 | Header recht 4p (raster 2.54) | 32.0000 | st 10350721 | Weerstand 220E 5% 1/4W | 12.0000 | st
10600438 | Header recht 16p nobox(R 2.54) | 12.0000 | st 10350725 | Weerstand 470E 5% 1/4W | 32.0000 | st
10600801 | Jack Bantam black chassis | 20.0000 | st 10350761 | Weerstand 470k 5% 1/4W | 6.0000 | st
10600800 | Jack Bantam blue chassis | 16.0000 | st 10350726 | Weerstand 560E 5% 1/4W | 4.0000 | st
10200720 | Print Merlin-pp1c (channelpp) | 4.0000 | st 10600234 | XLR chass mal 3p mt.bl ver p | 4.0000 | st
10600414 | Shunt 2p (mini-jumper) | 24.0000 | st 10250340 | Zenerdiode 2V4 / 400mW | 2.0000 | st
10650449 | Bandkabel 25p (R 1.27) | 200.0000 | cm 10100474 | Achterpl. Axion/Merlin15 1pos | 6.0000 | st
10650159 | Bandkabel 34p (R 1.27) | 1208.0000 | cm 10101194 | Achterpl. Cinemix 14B (master) | 1.0000 | st
10600132 | Connector bandkabel female 34p | 8.0000 | st 10101093 | Achterplaat Merlin13/c bl.8pos | 4.0000 | st
10600113 | Connector sub-D bandkb.fem 25p | 3.0000 | st 10700659 | Afstandshdr mt zeskant+tap15mm | 4.0000 | st
10600112 | Connector sub-D bandkb.mal 25p | 8.0000 | st 10650448 | Bandkabel 20p (R 1.27) | 925.0000 | cm
10700690 | Platstaf 25 x 10 x 10mm | 8.0000 | st 10650159 | Bandkabel 34p (R 1.27) | 280.0000 | cm
10700611 | Popnagel 3.0 x 6.5 blank | 16.0000 | st 10650451 | Bandkabel 64p (R 1.27) | 1800.0000 | cm
20850620 | Print bestukt Avalon-pp1(chan) | 4.0000 | st 10700290 | Bout M 6 x 45 fretbout blank | 24.0000 | st
60883375 Cinemix frame 32 ( 61 pos.) 10700911 | Bout M10 x 20 blank | 8.0000 | st
------------------------------------------------------------------------------------------------- 10600470 | Connector bandkabel female 20p | 64.0000 | st
Articlecode | Description | Quantity | Unit 10600132 | Connector bandkabel female 34p | 7.0000 | st
------------------------------------------------------------------------------------------------- 10600133 | Connector bandkabel female 64p | 90.0000 | st
10400216 | Condensator ker 18p R2.5 | 8.0000 | st 10600527 | Connector chass speakon 8p.zw. | 1.0000 | st
10400217 | Condensator ker 22p R2.5 | 6.0000 | st 10600482 | Connector instrumentklem zwart | 1.0000 | st
10400225 | Condensator ker 100p R2.5 | 2.0000 | st 10600526 | Connector plug speakon 4p.zw. | 1.0000 | st
10400229 | Condensator ker 220p R2.5 | 2.0000 | st 10700002 | Druknagel wit (nylon) | 7.0000 | st
10400232 | Condensator ker 470p R2.5 | 2.0000 | st 10700975 | Dubbelzijdig plakband 12mm dun | 427.0000 | cm
10401241 | Condensator ker 100nF/50V R5 T | 172.0000 | st 10100440 | Front Cinemix 17a ledblind | 1.0000 | st
10401253 | Condensator poly 10n R5.0 | 80.0000 | st 10101184 | Front Cinemix 4A (blind) | 1.0000 | st
10600114 | Connector chassis DIN fem 5p | 3.0000 | st 10101095 | Front Merlin 15b (afscherming) | 1.0000 | st
10600041 | Connector sub-D25 female pcb | 6.0000 | st 10500705 | Isolatieplaat midi mute PVC | 4.5000 | st
10250342 | Diode 1N4148(signaal) | 16.0000 | st 10600006 | Kabelschoen + boutgat M4 blauw | 4.0000 | st
10400284 | Elco 10uF / 40V radiaal R5.0 | 4.0000 | st 10600012 | Kabelschoen rondstift blauw | 6.0000 | st
10400292 | Elco 100uF / 25V radiaal R5.0 | 18.0000 | st 10600013 | Kabelschoen stifthouder blauw | 10.0000 | st
10400290 | Elco 220uF / 25V radiaal R5.0 | 11.0000 | st 10700422 | Kartelring M 4 (buitenvertan) | 2.0000 | st
10600452 | Header 10p haaks (raster 2.54) | 1.0000 | st 10700913 | Kartelring M 8 (buitenvertan) | 8.0000 | st
10600509 | Header 20P Straight | 40.0000 | st 10150081 | Kast Cinemix 32/D (61pos) | 1.0000 | st
10600512 | Header 4P lock straight(R2.54) | 6.0000 | st 10500682 | Krimpkous 6 mm (rond) | 16.0000 | cm
10600456 | Header haaks 20p (raster 2.54) | 1.0000 | st 10700007 | Magneetstrip 8.5mm x 3mm | 427.0000 | cm
10600140 | Header haaks 34p (raster 2.54) | 11.0000 | st 10700610 | Moer M 3 | 4.0000 | st
10600141 | Header haaks 64p (raster 2.54) | 4.0000 | st 10700686 | Moer M 8 | 8.0000 | st
10600478 | Header recht 4p (raster 2.54) | 18.0000 | st 10700612 | Moer M 10 | 8.0000 | st
10600435 | Header recht 10p nobox(R 2.54) | 2.0000 | st 10650490 | Montagedraad 2.5 mm2 (blauw) | 180.0000 | cm
10600142 | Header recht 34p (raster 2.54) | 4.0000 | st 10650101 | Montagedraad 2.5 mm2 (geel) | 275.0000 | cm
10250026 | Ic 27C512-10 EPROM 64K 100ns | 2.0000 | st 10650103 | Montagedraad 2.5 mm2 (grijs) | 240.0000 | cm
10250040 | Ic 40106B (hex schmitt trig) | 2.0000 | st 10650102 | Montagedraad 2.5 mm2 (groen) | 70.0000 | cm
10250025 | Ic 4051B (8 chann multiplexer) | 45.0000 | st 10650106 | Montagedraad 2.5 mm2 (oranje) | 275.0000 | cm
10250094 | Ic 4094 (8bit serial shiftreg) | 5.0000 | st 10650107 | Montagedraad 2.5 mm2 (paars) | 60.0000 | cm
10250014 | Ic 4N27(opto-coupler) | 2.0000 | st 10650100 | Montagedraad 2.5 mm2 (rood) | 240.0000 | cm
10250039 | Ic 62C256 (8 bit 32k ram) | 2.0000 | st 10650104 | Montagedraad 2.5 mm2 (zwart) | 720.0000 | cm
10250012 | Ic 74HC125 (quad bistab. buf) | 10.0000 | st 10650105 | Montagedraad 2.5 mm2 geel/grn | 50.0000 | cm
10250048 | Ic 74HC138 3to8 line decoder | 20.0000 | st 10700690 | Platstaf 25 x 10 x 10mm | 6.0000 | st
10250035 | Ic 74HC14 (hex inv.schmittrig) | 2.0000 | st 10101195 | Plexiglas Cinemix 32 (61 pos) | 1.0000 | st
10250033 | Ic 74HC573 (octal-D latch) | 2.0000 | st 10700611 | Popnagel 3.0 x 6.5 blank | 12.0000 | st
10250291 | Ic 7805 TO220 SGS (volt.reg) | 7.0000 | st 20851196 | Print bestukt CPUamp1 (autom.) | 2.0000 | st
10250036 | Ic 80C552 (8-bit micro-comptr) | 2.0000 | st 20851192 | Print bestukt Cinemix20(pwrco) | 2.0000 | st
10250068 | Ic CA3046 (transistor array) | 2.0000 | st 20851193 | Print bestukt Cinemix31(back2) | 1.0000 | st
10250069 | Ic DAC832 (8 bits DAC) | 2.0000 | st 20851194 | Print bestukt Cinemix32(back3) | 1.0000 | st
10250304 | Ic TL-072 CP TI (dual-opamp) | 6.0000 | st 20851189 | Print bestukt Cinemix9 (back1) | 1.0000 | st
10250305 | Ic TL-074 CN TI (quad-opamp) | 22.0000 | st 20851197 | Print bestukt MUXamp1 (autom.) | 5.0000 | st
10600394 | Ic-voet 8 pins (vork-contact) | 6.0000 | st 10700626 | Ring M 10 potmeter blank | 8.0000 | st
10600395 | Ic-voet 14 pins (vork-contact) | 38.0000 | st 10700009 | Rubber neopreenband 30 x 2 mm | 100.0000 | cm
10600396 | Ic-voet 16 pins (vork-contact) | 70.0000 | st 10100682 | Schrijfstrook 2800x28x3mm 62st | 214.0000 | cm
10600398 | Ic-voet 20 pins (vork-contact) | 4.0000 | st 10700700 | Schroef spaanplaat 4.5 x 30 | 2.0000 | st
10600401 | Ic-voet 28 pins (vork-contact) | 4.0000 | st 10700787 | Taptite M3x6 bolkoppozidr/zwrt | 358.0000 | st
10600403 | Ic-voet 68 pins (PLCC Socket) | 2.0000 | st 10700790 | Taptite M3x6 verzkop/pozidr/zw | 14.0000 | st
10300202 | Instelpot 22-turn 2k H T93YB | 2.0000 | st
10300200 | Instelpot 25-turn 20k H T93YB | 6.0000 | st
10250396 | Kristal 12.0000 MHz | 2.0000 | st
10250387 | Led 3mm red round | 4.0000 | st
10201196 | Print CPU-Amp1c (autom.) | 2.0000 | st
10201192 | Print Cinemix 20A (power con) | 2.0000 | st
10350848 | Weerstand 10k0 1% 1/4W | 14.0000 | st
10700689 | Bout M 8 x 20 tapbout zwart | 8.0000 | st
