-SOLO When the SOLO switch is activated the corresponding input (either
Direct or Playback) is put on the Cinemix's Solo buss, post TRIM control.
-MUTE Each individual track has it's own Mute switch which mutes the
output
of the track when activated.
Under the control switches of the individual tracks 3 more switches and a
trimpot
are positioned for control functions for the corresponding group of 6 inputs.
-DIR/PLBK The DIR/PLBK switch switches all 6 outputs between direct and
playback of all input channels that are put in TOGGLE mode (led in SET
switch off, see explanation SET switch).
-Master MUTE When activated this switch mutes all 6 tracks of the
corresponding group regardless the status of the individual mute settings.
When the Master MUTE switch is deactivated again all settings will be the
same as before the Master MUTE was activated.
-TRIM When the TRIM switch is activated, the master TRIM control pot can
be used to adjust the overall level of the corresponding 6 tracks when
necessary.
If the TRIM switch is deactivated the outputs are at a fixed level.
MODULE MASTER FUNCTIONS:
At the top of the module 6 master programming function switches are located.
These switches are used to define and program the master status of the
complete module.
-MAIN TO CRM When activated all main outputs (Left, Center, Right,
Surround Left, Surround Right and Subbass) are connected to the CRM
outputs.
-MATRIX TO MAIN When the MATRIX TO MAIN switch is activated the
summed outputs of the matrix are connected to the master summing buses
(L,C,R, Sl, Sr and SB) of the Cinemix. This feature can be used for final
tracklaydown in the recording process.
-MONO SRND With this switch the stereo surround outputs of the matrix can
be switched into mono signals to the Surround Left and Surround Right
outputs.
