D&R CinemIX - Functions; Individual Functions Per Track

NOTES:
Depending if a new backpanel is supplied with retrofit kits for older consoles
the cables may already be connected to the backpanel. These are the flatcables
that are lying on the bottom of the console.
Several connectors are provided which all can be used.
*** This also applies for any external meters if used.
FUNCTIONS:
The STEMS/Monitoring Matrix Module is built up of 4 identical sections.
Each section consists of 6 tracks, each track with a "Direct" and a
"Playback"input.
Each track has a dedicated "SET" , "SOLO" and "MUTE" switch.
A master "Direct/Playback" switch and a master "Mute" switch are positioned
at the bottom of each section together with the "Trim switch and pot.
At the top of the module 6 masterfunction switches are positioned called
"Main to CRM" , "Matrix to Main" , "Mono Surround" , "Matrix Setup" ,
"Preset A" and "Preset B".
INDIVIDUAL FUNCTIONS PER TRACK:
Each track consists of a strip starting at the top with a square indicating the
track number (1-24).
Under the tracknumber 6 assign Led's are positioned which show if the output
of the track is routed to either the Left , Right , Center , Surround Left,
Surround Right or Subbass master buses or CRM outputs.
- SET.
The SET switch is located under the 6 assign led's. The SET switch enables
the engineer to switch between the Direct and Playback signal. If the switch is
put in Toggle mode (led in the switch off) the track output can be switched
between Direct and Playback using the master Dir/Playback switch positioned
at the bottom of the section.
The 3 following modes are programmed in sequence under the SET switch.
1)-Direct : the led in the SET switch and the red led at the left above the
SET switch are lit.
2)-Playback : the led in the SET switch and the green led at the right above
the SET switch are lit.
3)-Toggle : the led in the SET switch is off. The green or red led is on,
depending of the position of the DIR/PLBK switch.
The SET switch is also used during the setup procedure of the module.
When the module is in setup mode the SEL switch is used to route the output
of the individual tracks to the 6 master outputs.
Cinemix manual page: 69
