Danfoss AK-CC 750 series

AK-CC 750 - 080Z0130 & 080Z0139 RS8GM222 © Danfoss 10-2014 13
Point
Signal Signal
type
S
Pt 1000 ohm/0°C
S2,
S3
S4,
S5
Saux
Pt 1000
P
AKS 32R
AKS 2050
AKS 32
P0
Pc
Paux
AKS 32R
AKS 2050
-1 - xx bar
AKS 32
-1 - zz bar
U
...
0 - 5 V
0 - 10 V
On/O Ext.
Main
switch
Day/
Night
Door
Defrost
Active at:
Closed
/
Open
DO
AKV
Fan
Alarm
Light
Rail heat
Defrost
Night
blind
Valves
Compres-
sor
Active at:
On
/
O
Signal Module Point
Terminal
Signal type /
Active at
1
1 (AI 1) 1 - 2
2 (AI 2) 3 - 4
3 (AI 3) 5 - 6
4 (AI 4) 7 - 8
5 (AI 5) 9 - 10
6 (AI 6) 11 - 12
7 (AI 7) 13 - 14
8 (AI 8) 19 - 20
9 (AI 9) 21 - 22
10 (AI 10) 23 - 24
11 (AI 11) 25 - 26
12 (DO 1) 31 - 32
13 (DO 2) 33 - 34
14 (DO 3) 35 - 36
15 (DO 4) 37 - 38
16 (DO 5) 39 - 40- 41
17 (DO6) 42 - 43 - 44
18 (DO7) 45 - 46 - 47
19 (DO8) 48 - 49 - 50
Terminal 15: 12 V
Terminal 16: 5 V
Terminal 27: 12 V
Terminal 28: 5 V
Terminal
17, 18, 29, 30:
(Cable screen)
Solid state outputs
on 12 - 15
Relay or AKV coil
fx 230 V a.c.
Relay outputs on
16 - 19
Analog
inputs
on 1 - 11
Point 1 2 3 4 5 6 7 8 9 10 11
Type AI1 AI2 AI3 AI4 AI5 AI6 AI7 AI8 AI9 AI10 AI11
Point 12 13 14 15 16 17 18 19
Type DO1 DO2 DO3 DO4 DO5 DO6 DO7 DO8
24 and 25 not
used at evapora-
tor control
3: Brown
2: Blue
1: Black
3: Brown
2: Black
1: Red
AKV
20-23*)
*) 20 - 23: See Case
power module
