Unlock the conguration of
the controllers
1. Go to Conguration menu
2. Select Lock/Unlock conguration
3. Select Conguration lock
Press the blue eld with the text Locked
4. Select Unlocked
Conguration - continued
The controller can only be congured when
it is unlocked.
It can only be adjusted when it is locked.
Changes to the input and output settings
are only enabled when the controller is
“Locked”
The values can be changed when it is locked,
but only for those settings that do not aect
the conguration.
3-
Main Switch
Used to start and stop regulation.
When the main switch is set to O, all outputs
are in standby mode and all alarms are
cancelled.
The main switch must be set to O before the
Conguration lock can be Unlocked.
Conguration lock
The controller can only be fully congured
when the conguration lock is set to Un-
locked.
The settings are only applied when it is set
to Locked again. At this point, the controller
checks the functions set and compares them
with the input and output settings.
Important settings can then no longer be
changed unless the conguration is unlocked
again.
If you want to know more about the dierent con-
guration options, they are listed below.
The number refers to the number and picture in the
column on the left.
In general
Many settings are dependent on previous set-
tings. This is shown by the fact that a function
can only be seen (and thus set) if an earlier
parent function allows access to this subordi-
nate function
For example, the “Conguration lock” line will not
be shown if the main switch is set to On. Only
when the main switch is set to O, and regulation
has therefore been stopped, is it possible to set
the conguration lock.
