Common data for modules
Supply voltage 24 V d.c. / a.c. +/- 20%
Power consumption AK-__ (controller) 8 VA
AK-XM 101, 102, 103 2 VA
AK-XM 204, 205 5 VA
Analog inputs Pt 1000 ohm /0°C Resolution: 0.1°C
Accuracy: +/- 0.5°C (between -58°F and +122°F)
PTC 1000 ohm /0°C
Pressure transmitter type AKS 32R / AKS
2050 / AKS 32 (1-5 V)
Resolution:1 mV
Accuracy +/- 10 mV
Max. connection of 5 pressure transmitters on one module
Voltage signal 0-10 V
Contact function (On/O ) On at R < 20 ohm
O at R > 2K ohm
(Gold -plated contacts not necessary)
On/o supply voltage inputs Low voltage
0 / 80 V a.c./d.c.
O: U < 2 V
On: U > 10 V
High voltage
0 / 260 V a.c.
O: U < 24 V
On: U > 80 V
Relay outputs
SPDT
AC-1 (ohmic) 4 A
AC-15 (inductive) 3 A
U Min. 24 V
Max. 230 V
Low and high voltage must not be connected to the same
output group
Solid state outputs Can be used for loads that are cut in and
out frequently, e.g. :
rail heat, fans and AKV valve
Max. 240 V a.c. , Min. 48 V a.c.
Max. 0.5 A,
Leak < 1 mA
Max. 1 AKV
Ambient temperature During transport -40 to 158°F
During operation -4 to 131°F ,
0 to 95% RH (non condensing)
No shock inuences / vibrations
Enclosure Material PC / ABS
Density IP10 , VBG 4
Mounting For mounting on panel wall or DIN rail
Weight with screw terminals modules in100- / 200- / controller-series Ca. 7 oz / 17 oz / 21 oz
Approvals EU low voltage directive and EMC require-
ments are complied with
LVD tested according to EN 60730
EMC tested
Immunity according to EN 61000-6-2
Emission according to EN 61000-6-3
UL 873,
UL le number: E166834
The mentioned data applies to all modules.
If data is specic, this is mentioned together with the module in question.
