Danfoss AK-CC 750 series User Manual

AK-CC 750 - 080Z0130 & 080Z0139 RS8GM222 © Danfoss 10-2014 9
Type Analog
inputs
On/O outputs On/o supply voltage
(DI signal)
Module with
switches
For sensors, pres-
sure transmitters
etc.
Relay
(SPDT)
Solid state Low voltage
(max. 80 V)
High voltage
(max. 260 V)
For override of relay
outputs
Controller 11 4 4 - - -
Extension modules
AK-XM 101A 8
AK-XM 102A 8
AK-XM 102B 8
AK-XM 204A 8
AK-XM 204B 8 x
AK-XM 205A 8 8
AK-XM 205B 8 8 x
Type Function Application
Operation
AK-ST 500 Software for operation of AK controllers AK-operation
- Cable between PC and AK controller AK - Com port
-
Cable between zero modem cable and AK controller /
Cable between PDA cable and AK controller
AK - RS 232
- Cable between PC and AK controller AK - USB
Accessories Transformer module 230 V / 115 V to 24 V
AK-PS 075 18 VA, 24 V d.c.
Supply for controller
AK-PS 150 36 VA, 24 V d.c.
Accessories External display that can be connected to the controller module. For showing, say, the refrigeration appliances
EKA 163B Display
EKA 164B Display with operation buttons
- Cable between display and controller
Length = 6.5 ft
Length = 19.5 ft
Accessories Real time clock for use in controllers that require a clock function, but are not wired with data communication.
AK-OB 101A Real time clock with battery backup. To be mounted in an AK controller
Type Function Application
AK-CC 750 Controller for evaporator control Refrigeration appliances control
1. Controller
2. Extension modules and survey of inputs and outputs
3. AK operation and accessories
On the following pages there is data specic to each module.
