AK-CC 750 - 080Z0130 & 080Z0139 RS8GM222 © Danfoss 10-2014 19
Point
Signal Module Point Terminal Active at
1 (DO 1) 25 - 27
2 (DO 2) 28 - 30
3 (DO 3) 31 - 33
4 (DO 4) 34 -36
5 (DO 5) 37 - 39
6 (DO 6) 40 - 41 - 42
7 (DO 7) 43 - 44 - 45
8 (DO 8) 46 - 47 - 48
Signal Active at
DO
Fan
Alarm
Light
Railheat
Defrost
Night
blind
Valve
Compres-
sor
On
/
O
Point 1 2 3 4 5 6 7 8
Type DO1 DO2 DO3 DO4 DO5 DO6 DO7 DO8
