Danfoss AK-CC 750 series

92 RS8GM222 © Danfoss 10-2014 AK-CC 750 - 080Z0130 & 080Z0139
8 4 EEV LT
CPM
AI Points (Base Module)
AI Point (Expansion Module)
1-1 1-2 1-3 1-4 1-5 1-6 1-7 1-8
1-9 1-10 1-11 2-1 2-2 2-3 2-4 2-5 2-6 2-7
Disc Air A Evap Out A Def Term A Disc Air B Evap Out B Def Term B Disc Air C Evap Out C
Def Term C PE Pressure Door Sw Disc Air D Evap Out D Def Term D Dual - Temp
DO Points (Base Module)
Power Module Connector DO Point (Expansion Module)
1-12 1-13 1-14 1-15 1-16 1-17 1-18 1-19
1-20 1-21 1-22 1-23 2-9 2-10 2-11 2-12 2-13 2-14 2-15
EEV A EEV B EEV C EEV D
ASH Light Def Fan
9 Uncon-
nected DOs
(OK)
4 EEV LT
CPM NoT
AI Points (Base Module)
1-1 1-2 1-3 1-4 1-5 1-6 1-7 1-8
1-9 1-10 1-11
Disc Air A Evap Out A Disc Air B Evap Out B Disc Air C Evap Out C Disc Air D Evap Out D
Dual Temp PE Pressure Door Sw
DO Points (Base Module)
Power Module Connector
1-12 1-13 1-14 1-15 1-16 1-17 1-18 1-19
1-20 1-21 1-22 1-23
EEV A EEV B EEV C EEV D
ASH Light Def Fan
10 Uncon-
nected DOs
(OK)
4 EEV MT AI Points (Base Module)
1-1 1-2 1-3 1-4 1-5 1-6 1-7 1-8
1-9 1-10 1-11
Disc Air A Evap Out A Disc Air B Evap Out B Disc Air C Evap Out C Disc Air D Evap Out D
PE Pressure Door Sw
DO Points (Base Module)
1-12 1-13 1-14 1-15 1-16 1-17 1-18 1-19
EEV A EEV B EEV C EEV D Fan Light Def
11 Uncon-
nected DOs
(OK)
4 EEV MT
CPM
AI Points (Base Module)
1-1 1-2 1-3 1-4 1-5 1-6 1-7 1-8
1-9 1-10 1-11
Disc Air A Evap Out A Disc Air B Evap Out B Disc Air C Evap Out C Disc Air D Evap Out D
PE Pressure Door Sw
DO Points (Base Module)
Power Module Connector
1-12 1-13 1-14 1-15 1-16 1-17 1-18 1-19
1-20 1-21 1-22 1-23
EEV A EEV B EEV C EEV D
ASH Light Def Fan
12 4 EEV
Comm
Term
AI Points (Base Module)
AI Point (Expansion Module)
1-1 1-2 1-3 1-4 1-5 1-6 1-7 1-8
1-9 1-10 1-11 2-1 2-2 2-3 2-4 2-5 2-6 2-7 2-8
Disc A Dt A Disc B Dt B Disc C Dt C Disc D Dt D
PE dr Sw EpO A EpO B EpO C EpO D ----
DO Points (Base Module)
DO Point (Expansion Module)
1-12 1-13 1-14 1-15 1-16 1-17 1-18 1-19
2-9 2-10 2-11 2-12 2-13 2-14 2-15 2-16
Valve A Valve B Valve C Valve D Fan Light DEF ASH
---- ---- ---- ---- ---- ---- ---- ----
13 4 EEV Ind
Term
AI Points (Base Module)
AI Point (Expansion Module)
1-1 1-2 1-3 1-4 1-5 1-6 1-7 1-8
1-9 1-10 1-11 2-1 2-2 2-3 2-4 2-5 2-6 2-7 2-8
Disc A Dt A Disc B Dt B Disc C Dt C Disc D Dt D
PE dr Sw EpO A EpO B EpO C EpO D ----
DO Points (Base Module)
DO Point (Expansion Module)
1-12 1-13 1-14 1-15 1-16 1-17 1-18 1-19
2-9 2-10 2-11 2-12 2-13 2-14 2-15 2-16
Valve A Valve B Valve C Valve D Fan Light Def A ASH
Def B Def C Def D ---- ---- ---- ---- ----
14 4 EEV AD C
Term
AI Points (Base Module)
AI Point (Expansion Module)
1-1 1-2 1-3 1-4 1-5 1-6 1-7 1-8
1-9 1-10 1-11 2-1 2-2 2-3 2-4 2-5 2-6 2-7 2-8
Disc A Dt A Disc B Dt B Disc C Dt C Disc D Dt D
Rt A PE dr Sw Rt B Rt C Rt D EpO A EpO B EpO C EpO D ----
DO Points (Base Module)
DO Point (Expansion Module)
1-12 1-13 1-14 1-15 1-16 1-17 1-18 1-19
2-9 2-10 2-11 2-12 2-13 2-14 2-15 2-16
Valve A Valve B Valve C Valve D Fan Light DEF ASH
---- ---- ---- ---- ---- ---- ---- ----
15 4 EEV AD I
Term
AI Points (Base Module)
AI Point (Expansion Module)
1-1 1-2 1-3 1-4 1-5 1-6 1-7 1-8
1-9 1-10 1-11 2-1 2-2 2-3 2-4 2-5 2-6 2-7 2-8
Disc A Dt A Disc B Dt B Disc C Dt C Disc D Dt D
Rt A PE dr Sw Rt B Rt C Rt D EpO A EpO B EpO C EpO D ----
DO Points (Base Module)
DO Point (Expansion Module)
1-12 1-13 1-14 1-15 1-16 1-17 1-18 1-19
2-9 2-10 2-11 2-12 2-13 2-14 2-15 2-16
Valve A Valve B Valve C Valve D Fan Light Def A ASH
Def B Def C Def D ---- ---- ---- ---- ----
16 4 EEV DT C
Term
AI Points (Base Module)
AI Point (Expansion Module)
1-1 1-2 1-3 1-4 1-5 1-6 1-7 1-8
1-9 1-10 1-11 2-1 2-2 2-3 2-4 2-5 2-6 2-7 2-8
Disc Air A Evap Out A Def Term A Dual Temp A Disc Air B Evap Out B Def Term B Dual Temp B
Disc Air C Pe pressure Door Sw Evap Out C Def Term C Dual Temp C Disc Air D Evap Out D Def Term D Dual Temp D
DO Points (Base Module)
DO Point (Expansion Module)
1-12 1-13 1-14 1-15 1-16 1-17 1-18 1-19
2-9 2-10 2-11 2-12 2-13 2-14 2-15 2-16
EEV A EEV B EEV C EEV D Fan Light Def ASH
17 4 EEV DT I
Term
AI Points (Base Module)
AI Point (Expansion Module)
1-1 1-2 1-3 1-4 1-5 1-6 1-7 1-8
1-9 1-10 1-11 2-1 2-2 2-3 2-4 2-5 2-6 2-7 2-8
Disc Air A Evap Out A Def Term A Dual Temp A Disc Air B Evap Out B Def Term B Dual Temp B
Disc Air C Pe pressure Door Sw Evap Out C Def Term C Dual Temp C Disc Air D Evap Out D Def Term D Dual Temp D
DO Points (Base Module)
DO Point (Expansion Module)
1-12 1-13 1-14 1-15 1-16 1-17 1-18 1-19
2-9 2-10 2-11 2-12 2-13 2-14 2-15 2-16
EEV A EEV B EEV C EEV D Fan Light Def A ASH
Def B Def C Def D
