Danfoss APP series User Manual

5
180R9265 / IOM APP 16-22 Appendices - v02 / 01.2013
Data sheet APP 16-22
t One of the smallest and lightest pumps on
the market
t Can be powered by a combustion engine
provided that a special coupling is used.
t Long service life / No preventive mainte-
nance required in the warranty period.
t Generates insignicant pulsations in the
pressure line.
tNo oil lubricant required
tIntegrated ushing valve
t All parts of the pump are made of non-
corrosive materials, e.g. Duplex (EN1.4462/
UNS S31803-S32205) and Super Duplex
(EN1.4410/UNS S32750) stainless steel and
carbon reinforced PEEK
tHigh eciency
2. Benets
3. Technical data
APP Pumps APP 16
1200
APP 16
1500
APP 17
1200
APP 17
1500
APP 19
1200
APP 19
1500
APP 22
1200
APP 22
1500
Code number 180B3254 180B3250 180B3255 180B3251 180B3256 180B3252 180B3257 180B3253
Geometric displacement cm³/rpm 235 185 252 198 272 220 311 252
in³/rpm 14.3 11. 3 15.4 12.1 16.6 13.4 19.0 15.4
Rated ow at max speed
1)
m³/h 16 15.8 17.2 16.9 18.8 18.8 21.5 21.7
gpm 70.4 69.6 75.7 74.4 82.8 82.8 94.7 95.5
Outlet min. Pressure
2)
bar 30 30 30 30 30 30 30 30
psi 435 435 435 435 435 435 435 435
Outlet max. Pressure,
continuous
3)
bar 80 70 80 70 80 70 80 70
psi 116 0 1015 116 0 1015 116 0 1015 116 0 1015
Inlet min. Pressure bar 2 2 2 2 2 2 2 2
psi 29 29 29 29 29 29 29 29
Inlet max. Pressure, continuous bar 5 5 5 5 5 5 5 5
psi 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
Inlet max. Pressure, peak bar 10 10 10 10 10 10 10 10
psi 145 145 145 145 145 145 145 145
Max. Speed continuous rpm 1200 1500 1200 1500 1200 1500 1200 1500
Min. Speed continuous rpm 700 700 700 700 700 700 700 700
Power requirement at max.
speed and 60 bar outlet
pressure
kW 32 31 35 33 38 37 43 43
hp 42.9 41.6 46.9 44.3 51.0 49.6 57.7 57.7
Torque at 60 bar outlet
pressure
Nm 258 196 276 210 299 236 341 273
lbf-ft 190.3 144.6 203.6 154.9 220.5 174.1 251.5 201.4
Weight kg 78 78 78 78 78 78 78 78
lb 172 172 172 172 172 172 172 172
Integrated ushing valve Yes Yes Yes Yes Yes Yes Yes Yes
1)
Typical average ow at 60 bar (870 psi)
2)
For lower pressure, please contact Danfoss
RO Sales Organization
3)
For higher pressure, please contact Danfoss
RO Sales Organization
The pump is designed according to EN809.
All parts included in the pumps are designed to
provide long service life, i.e. long service life with
a constantly high eciency and minimum
service required.
The pumps are xed displacement pumps in
which the ow is proportional to the number of
revolutions of the input shaft and the pump
displacement.
