Instruction APP pump instruction APP 11-13 and APP 16-22
Description APP 11 - APP 13
Parallel key,
DIN 6885
mm
10 × 8 × 45
inch
0.39 × 0.31 × 1.77
Bleeding
G ¼”, Hexagon AF = 6 mm
Inlet port
M42 x 1.5; depth 17 mm
Outlet port
M42 x 1.5; depth 17 mm
Pump mounting
ange
125 B 4
Accessories Type Code no.
2” inlet hose kit
2 m / 79”
2” Victaulic 180Z0298
2” inlet Vic.
Super Duplex
2” Victaulic 180Z0166
Non-return
valve (outlet)
Super Duplex
1,5” Victaulic
(OD 48,3 mm)
180H0053
For more details on the accessories, please
contact the Danfoss RO Solutions Sales
Organisation.
Description APP 16 – APP 22
Parallel key,
DIN 6885
mm
12 × 8 × 70
In
0.47 × 0.31 × 2.76
Bleeding
G ¼”, Hexagon AF = 6 mm
Inlet port
M52 x 1.5; depth 21 mm
Outlet port
M52 x 1.5; depth 21 mm
Pump mounting
ange
125 B 4
Accessories Type Code no.
2” inlet hose
kit 2 m/79”
2” Victaulic 180Z0298
2” inlet Vic.
Super Duplex
2” Victaulic 180Z0165
Non-return
valve (outlet)
Super Duplex
2” Victaulic
(OD 63 mm)
180H0256
For more details on the accessories, please
contact the Danfoss RO Solutions Sales
Organisation.
APP 11 - APP 13
APP 16 – APP 22
