Danfoss ECL 2000 Installation Guide

Configuring the ECL 2000
EI.65.D4.02
29
Sensor Amplific.
range
Amplific.
default
Unit Offset
range
Energy
0.00 –9.99
10.0 – 99.9
10 kW
(per V)
± 0.00 – 9.99
± 10.0 – 100.0
0.10 – 9.99
10.0 – 99.9
MW
(per V)
Other
1–0
Example 1 A flow meter yields a voltage of 0 V at zero flow and 5 V at 10 m
3
/h. In this case,
Amplific. and Offset are set as follows:
• Amplific. = 2 m
3
/h (per V)
• Offset = 0.
Example 2 A sun intensity meter yields a voltage of 2 V when no light at all is present. The
voltage is 10 V when the meter detects a sun intensity of 40 W/m
2
. Amplific. and
Offset are set as follows:
• Amplific. = 5 W/m
2
(per V)
• Offset = – 10 W/m
2
.
