17Installation Guide
P06 Minimum
Room Temp.
Limitation
5-35˚C(Active in
Temperature Control
Mode 02)
5˚C
P07 Setting range
extension for
P06, P07, P08
01: Max. 35˚C, 02:
Max. 45˚C
01
P08 Only room
temperature
control
01: Enable, 02:
Disable
02
5 Error Codes
E1 Room sensor failure
E2 Floor sensor failure
EE EEPROM failure
Lo Temperature lower than 0˚C
Hi Temperature higher than 5˚C
All relay output will be turned o in all cases.
6 Warranty
YEAR
WARRANTY

Danfoss ECtemp Next Plus Specifications

General

Voltage	220 - 240 V
Temperature range (T-T)	-10 - 60 °C
Temperature control range	5 - 45 °C
Power source	AC
Power consumption (standby)	2 W
Product color	White
Memory function	-
Housing material	Plastic
Smart thermostat	Yes
International Protection (IP) code	IP30

Weight and Dimensions

Depth	16 mm
Width	86 mm
