Danfoss ECtemp Next Plus User Manual

Danfoss ECtemp Next Plus
9Installation Guide
4 Settings
4�1 Power ON/OFF
Switch thermostat ON/OFF by pressing button on top of
thermostat.
4�2 Initial Settings
Initial settings must be specied when the unit is activated
for the rst time:
Press M button for 6 seconds to enter the parameter setting
mode.
The upper digits indicate the parameter number.
Press M for parameter selection.
Press < or > to set the parameter range.
Complete all adjustments.
Press to exit ECtemp Next Plus settings, which is available
for this purpose.
To exit ECtemp Next settings automatic wait approx. 30
seconds.

Danfoss ECtemp Next Plus Specifications

General

Voltage	220 - 240 V
Temperature range (T-T)	-10 - 60 °C
Temperature control range	5 - 45 °C
Power source	AC
Power consumption (standby)	2 W
Product color	White
Memory function	-
Housing material	Plastic
Smart thermostat	Yes
International Protection (IP) code	IP30

Weight and Dimensions

Depth	16 mm
Width	86 mm
