Danfoss ECtemp Next Plus User Manual

Danfoss ECtemp Next Plus
5Installation Guide
Standard “Automatic electrical controls for household and
similar use”:
• EN/IEC 60730-1 (general)
• EN/IEC 60730-2-9 (thermostat)
1�2 Safety Instructions
Make sure the mains supply to the thermostat is turned o
before installation.
Important: When the thermostat is used to control a oor
heating element in connection with a wooden oor or
similar material, always use a oor sensor and never set the
maximum oor temperature to more than 35°C.
Please also note the following:
• The installation of the thermostat must be done by an
authorized and qualied installer according to local
regulations.
• The thermostat must be connected to a power supply
via an all-pole disconnection switch.
• Always connect the thermostat to continuous power
supply.
• Do not expose the thermostat to moisture, water, dust,
and excessive heat.

Danfoss ECtemp Next Plus Specifications

General

Voltage	220 - 240 V
Temperature range (T-T)	-10 - 60 °C
Temperature control range	5 - 45 °C
Power source	AC
Power consumption (standby)	2 W
Product color	White
Memory function	-
Housing material	Plastic
Smart thermostat	Yes
International Protection (IP) code	IP30

Weight and Dimensions

Depth	16 mm
Width	86 mm
