Danfoss FC 300 Series User Manual

8-53 Start Select
Option: Function:
Select control of the adjustable frequency drive
start function via the terminals (digital input)
and/or via the serial communication bus.
[0] Digital
input
Activates Start command via a digital input.
[1] Bus Activates Start command via the serial communi-
cation port or serial communication option.
[2] Logic AND Activates Start command via the serial communi-
cation bus/serial communication port, AND
additionally via one of the digital inputs.
[3]
* Logic OR Activates Start command via the serial communi-
cation bus/serial communication port OR via one
of the digital inputs.
8-54 Reverse Select
Option: Function:
[0] Digital
input
Select control of the adjustable frequency drive
reverse function via the terminals (digital input)
and/or via the serial communication bus.
[1] Bus Activates the reverse command via the serial
communication port or serial communication
option.
[2] Logic AND Activates the reverse command via the serial
communication bus/serial communication port,
AND additionally via one of the digital inputs.
[3]
* Logic OR Activates the reverse command via the serial
communication bus/serial communication port
OR via one of the digital inputs.
8-55 Set-up Select
Option: Function:
Select control of the adjustable frequency drive
set-up selection via the terminals (digital input)
and/or via the serial communication bus.
[0] Digital
input
Activates the set-up selection via a digital input.
[1] Bus Activates the set-up selection via the serial
communication port or serial communication
option.
[2] Logic AND Activates the set-up selection via the serial
communication bus/serial communication port,
AND additionally via one of the digital inputs.
[3]
* Logic OR Activate the set-up selection via the serial
communication bus/serial communication port
OR via one of the digital inputs.
8-56 Preset Reference Select
Option: Function:
Select control of the adjustable frequency drive
Preset Reference selection via the terminals
(digital input) and/or via the serial communi-
cation bus.
[0] Digital
input
Activates Preset Reference selection via a digital
input.
[1] Bus Activates Preset Reference selection via the serial
communication port or serial communication
option.
[2] Logic AND Activates Preset Reference selection via the serial
communication bus/serial communication port,
AND additionally via one of the digital inputs.
[3]
* Logic OR Activates the Preset Reference selection via the
serial communication bus/serial communication
port OR via one of the digital inputs.
8-57 Profidrive OFF2 Select
Select control of the drive OFF2 selection via the terminals (digital
input) and/or via the serial communication bus. This parameter is
active only when par. 8-01 Control Site is set to [0] Digital and ctrl.
word and par. 8-10 is set to [1] Profidrive profile.
Option: Function:
[0] Digital input
[1] Bus
[2] Logic AND
[3]
* Logic OR
8-58 Profidrive OFF3 Select
Select control of the drive OFF3 selection via the terminals (digital
input) and/or via the serial communication bus. This parameter is
active only when par. 8-01 Control Site is set to [0] Digital and
control word and par. 8-10 is set to [1] Profidrive profile.
Option: Function:
[0] Digital input
[1] Bus
[2] Logic AND
[3]
* Logic OR
3.10.6 8-8* AFD Port Diagnos.
These parameters are used for monitoring the bus communi-
cation via the Port.
8-80 Bus Message Count
Range: Function:
0 N/A * [0 - 0 N/A] This parameter shows the number of valid
messages detected on the bus.
Parameter Descriptions FC 300 Programming Guide
MG.33.MA.22 - VLT
®
is a registered Danfoss trademark 3-89
3
3
