Danfoss FC 302 User Manual

FC 300 Instruction Manual
How to Program
" 17-** Motor Feedb.Option
Par.
No.
#
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Typ e
17-1* Inc. Enc. Interface
17-10 Signal Type
[1] RS422 (5V
TTL/linedrv. ) All set-ups FALSE - Uint8
17-11 Resolution (PPR) 1024 N/A All set-ups FALSE 0 Uint16
17-2*Abs.Enc.Interface
17-20 Protocol Selection [0] None All set-ups FALSE - Uint8
17-21 Resolution (Positions/Rev) [32768] 32768 All set-ups FALSE - Uint16
17-34 HIPERFACE Baudrate [4] 9600 All set-ups FALSE - Uint8
17-6* Monitoring and App.
17-60 Encoder Positive Direction [0] Clockwise All set-ups FALSE - Uint8
*
default setting ()display text []value for use in communication via serial communication port
59
MG.33.A
4.22 - VLT is a registered Danfoss trademark

Danfoss FC 302 Specifications

General

Model	FC 302
Brand	Danfoss
Protection Class	IP20
Communication Interface	RS485, PROFIBUS
Relative Humidity	5-95% (non-condensing)
Ambient Temperature	-10 to 45 / 50 °C (depending on enclosure)
Storage Temperature	-25 to 65°C
