Nomen-
clature
Parameter
FLX series
10 12.5 15 17
I
acmax
Max. current AC
3 x 15.1 A 3 x 18.8 A 3 x 22.6 A 3 x 25.6 A
AC current distortion
(THD at nominal
output power, %)
-<2 %
Inrush current 0.5 A / 10 ms
cosphi
ac,r
Power factor at
100% load
>0.99
Controlled power
factor range
0.8 over-excited
0.8 under-excited
Standby
consumption
2.7 W
f
r
Nominal grid
frequency (range)
50 (
±
5 Hz)
DC
Max. PV input power
per MPPT
8 kW
Nominal power DC 10.4 kW 12.9 kW 15.5 kW 17.6 kW
V
dc,r
Nominal voltage DC
715 V
V
dcmin
/
V
mppmin
-
V
mppmax
MPP voltage - active
tracking
2)
/ rated
power
3)
220/430 - 800 V 220/360 - 800 V 220/430 - 800 V 220/485 - 800 V
MPP efficiency, static 99.9%
MPP efficiency,
dynamic
99.7%
V
dcmax
Max. DC voltage
1000 V
V
dcstart
Turn on voltage DC
250 V
V
dcmin
Turn off voltage DC
220 V
I
dcmax
Max. MPP current
12 A per PV input
Max. short-circuit
current DC (at STC) 13.5 A per PV input
Min. on grid power 20 W
Efficiency
Max. efficiency 98%
Euro efficiency, V at
dc,r
97.0% 97.3% 97.4% 97.4%
Other
Dimensions (H, W,
D), inverter / incl.
packaging
667 x 500 x 233 mm / 774 x 570 x 356 mm
Mounting
recommendation
Mounting plate
Weight, inverter /
incl. packaging
38 kg / 44 kg 39 kg / 45 kg
Acoustic noise level
4
-55 dB(A)
MPP trackers 2 3
Operation
temperature range
-25..60 °C
Nom. temperature
range
-25..45 °C
Technical Data
36 L00410568-02_02 / Rev. date: 2013-12-10
