Power
rating
Drive
type
Enclosure size Enclosure size with
extended options cabinet
Number of drive modules
N75K H D1h/D3h D5h/D6h –
N90K H D1h/D3h D5h/D6h –
N110 H D1h/D3h D5h/D6h –
N132 H D1h/D3h D5h/D6h –
N160 H D1h/D3h D5h/D6h –
N200 H D2h/D4h D7h/D8h –
N250 H D2h/D4h D7h/D8h –
N315 H D2h/D4h D7h/D8h –
N315 P6 Db2 – 2-module system
N400 H D2h/D4h D7h/D8h –
N400 P6 Db2 – 2-module system
N450 P6 Db2 – 2-module system
N450 H E1h/E3h – –
N500 P6 Db2 – 2-module system
N500 H E1h/E3h – –
N560 P6 Db2 – 2-module system
N560 H E1h/E3h – –
N630 P6 Db2 – 2-module system
N630 H E1h/E3h – –
N710 P2 Da4 – 4-module system
N710 P6 Db4 – 4-module system
N710 H E2h/E4h – –
N800 P2 Da4 – 4-module system
N800 P6 Db4 – 4-module system
N800 H E2h/E4h – –
N900 P2 Da4 – 4-module system
N900 P6 Db4 – 4-module system
N1M0 P2 Da4 – 4-module system
N1M0 P6 Db4 – 4-module system
N1M2 P2 Da4 – 4-module system
N1M2 P6 Db4 – 4-module system
Table 3.9 525–690 V AC (T7) Voltage Rating for FC 102, FC 103, and FC 202
