12.3.2 Blank Mounting Plate
NOTICE
PARTS CONFIGURATION
In VLT
®
Parallel Drive Modules, the mounting plate is blank and does not hold a control card. In parallel drive systems,
the control card is found on the system control shelf, not in the individual modules.
To remove or replace the blank mounting plate, use the following steps. Refer to Illustration 12.8.
Disassembly
1. Remove the front cover of the parallel drive
module.
2. Remove the blank LCP cover. The cover can be
removed by hand.
3. Remove 4 screws (T20), 1 from each corner of the
blank mounting plate.
Reassembly
Tighten fasteners according to chapter 14.1 Fastener Torque
Ratings.
1. Position the blank mounting plate in the unit.
2. Secure 4 screws (T20), 1 in each corner of the
blank mounting plate.
3. Replace the blank LCP cover. The cover can be
replaced by hand.
4. Replace the front cover of the drive module.
Da2/Db2/Da4/Db4 Parallel Sy... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 257
12 12
